5kg Jumbo Roll / Maxi Roll Paper Rewinding and Slitting Machine

Feature:
1. Jumbo roll width: 1350-2800mm
2. Max. Rewinding diameter: 500mm

Jumbo roll slitting machine means slitting material paper into big roll reel shape toilet paper, Mainly used for a large restaurants, public toilets, such as the toilet of hotels, and airports.



Features of 5kg Jumbo Roll / Maxi Roll Paper Rewinding and Slitting Machine :

Jumbo roll slitting machine means slitting material paper into big roll reel shape toilet paper, Mainly used for a large public toilet, such as the toilet of hotels, and airports.
1. Use of inflatable shaft winding, so that accurate positioning is a simple paper tube.
2. Edge pressing system: Using steel on steel blank pressing, independent cylinder adjustment, to facilitate adjustment to each layer of paper is not hierarchical.
3. Horizontal style unwind stander, pneumatic paper loading unit, dispense artificially handling.
4. Deliver paper with a pneumatic wide belt, with a separate tension control device in each roll of raw paper.
5. Use of traction before and after the point of switch base paper, the operation is more simple and safe

Specification of 5kg Jumbo Roll / Maxi Roll Paper Rewinding and Slitting Machine :

Maximum Material Width 1350mm~2750mm
Maximum rewinding diameter Φ500mm
Core diameter Φ80mm(Can be special order)
Maximum material diameter 1100mm≤(Can be special order)
Jumbo roll core diameter φ76mm(Can be special order)
Perforated distance 4 knifives Sprial Type(115mm)(Can be special order)
Speed 0~180m/min
PLC PLC(Delta)
Jumbo roll stand 1~3 ply
Pneumatic System 3 Hp Air Compressor,Min. Pressure 5kg/㎡Pa (Customer supply)
Equipment, electric power 15KW
Dimensions 7500*4500*1800(L*W*H)
Weight About 4T
Paper weight per-square meter 15~22 g/㎡
Power 380V 50HZ

toilet paper kithen towel paper maxi roll machine
